50 Watt Amplifier

Item #:EVS-50W
You must be logged in to order this item.
Log in here
EVS-50W

The EVS-50W is an intelligent 50 watt amplifier for use with version 14.0 or newer 5820XL-EVS. The EVS-50W is used to amplify audio messaging throughout an area or facility. The EVS-50W is capable of producing 50 watts of audio power over 4, expandable to 8, fully programmable speaker circuits.

Features

  • 50 watts of audio power
  • Comes with 4 fully programmable Class A or Class B speaker circuits
  • 25 or 70.7 Vrms operation
  • Expansion up to 8 speaker circuits with the EVS-CE4
  • Six wire connection to the 5820XL-EVS system: two wires for the Voice Bus (VBUS) and four wires for the SBUS connections
  • Can be mounted up to 6000 feet away from the 5820XL-EVS control panel
  • 120 VAC or 240 VAC operation
  • UL 864 and UL 2572
